Fully Automatic Double-head Ultrasonic Welding Machine HY2-AFB003

The HYFB-003 is a fully automatic double-head ultrasonic welding machine designed for high-efficiency wire harness processing. It integrates wire feeding, cutting, burr pressing, and ultrasonic welding into one streamlined operation, making it ideal for mass production of consistent, high-quality wire harness assemblies.

Tel：18420496864

 Online

Product Details

Video

Technical Parameters：

Parameter	Specification
Model	HYFB-003 Double-Head Welding Machine
Power Supply	AC 380V / 50Hz (Note: "H2" in the original text is assumed to be a typo for "Hz")
Air Pressure	0.6MPa
Functions	Wire feeding & cutting, burr pressing, double-head ultrasonic welding
HMI & Control	Touch screen, PLC control
Processing Length	60–100mm
Quality Inspection	Sensor-based detection for material orientation (front/back)
Production Capacity	240 pcs/hour
Main Equipment Dimensions (L×W×H)	3100 × 1100 × 1800mm (excluding protrusions)
