Mechanical dimensions

L1600 × W700 × H1200 (mm)

L1600 × W700 × H1200 (mm)

Box size

L1000 × W400 × H280 (mm)

L1000 × W400 × H280 (mm)

Heating space

L1000 × W360 × H100 (mm)

L1000 × W360 × H100 (mm)

Mechanical weight

105kg

110kg

Conveying speed

0~6m/min

0~6m/min

Mechanical power

7.2KW (optional 4.0KW)

8KW

Conveying capacity

20kg

20kg

Material of conveyor belt

High-temperature-resistant PTFE mesh belt

High-temperature-resistant PTFE mesh belt

Heating temperature

0~260°C

0~300°C

Heating method

Dual temperature control (double-sided heating)

Dual temperature control (double-sided heating)

Heating tube

Far-infrared heating tube

Thermal radiation heating tube

Hot air fan

Yes

Yes

Heat dissipation device

Yes

Yes

Belt guide

Yes

Yes

Power supply

AC 380V (optional AC220V) 50HZ

AC 380V 50HZ
