Model

HY10-A1024PH3

Mechanical dimensions

L1600 × W480 × H1200 (mm)

Box size

L1090 × W240 × H200 (mm)

Mechanical weight

90kg

Conveying speed

0~6m/min

Mechanical power

5.4KW

Conveying capacity

20kg

Material of conveyor belt

High-temperature-resistant Teflon mesh belt

Heating temperature

0~260℃

Heating method

Dual temperature control (double-sided heating)

Heating tube

Far-infrared heating tube

Hot air fan

Yes

Belt guide

Yes

Power supply

AC 220V 50Hz
