Feature：
Broad Compatibility: Handles single wires up to 4mm² and double wires up to 2.5mm², supporting PVC, PTFE (Teflon), and glass wires. With 13 programmable middle stripping points, it easily accommodates complex wire processing needs.
Efficient & Adjustable: Boasts a high throughput of 5,000–10,000 pieces/hour (for 100mm wires). Both the cutter and feed speeds are independently adjustable (0–9 levels), allowing full customization for different materials and production requirements.
Technical Parameters：
| Parameter | Specification |
|---|---|
| Weight | 28kg |
| Power Supply | AC 220/110V, 50/60Hz |
| Motor Power | Rated 300W |
| Display Mode | Bilingual (Chinese/English) LCD display |
| Dimensions (L×W×H) | 460 × 470 × 325mm |
| Cutting Length Range | 1~10000mm |
| Stripping Length | Head end: 0~30mm, Tail end: 0~15mm |
| Cutting Tolerance | ±(0.002×L)mm |
| Middle Stripping Points | 13 positions |
| Applicable Wire Cross-Section | Double wire: 0.1~2.5mm²; Single wire: 0.1~4mm² |
| Max Conduit Diameter | 6mm |
| Applicable Wire Types | PVC, PTFE, glass wire |
| Blade Material | Hard tungsten steel |
| Stripping Speed | 5000~10000 pieces/hour (at L=100mm) |
| Drive Mode | 4-wheel drive (silent hybrid stepper motor, 0.1mm per step) |
| Adjustable Speed | Cutter speed, feed speed are independently adjustable (0=slowest, 9=fastest) |
