Ideal for processing large-gauge cables in automotive, energy, and industrial wire harness applications,
this high-performance machine combines servo-driven precision, robust construction, and user-friendly
operation to deliver reliable, high-volume results.
![]() |
![]() |
Feature:
Heavy-Duty Compatibility: Handles round sheaths up to 25mm outer diameter and conductors up to 185mm² (max 120mm² for hard wire, 185mm² for flexible wire), supporting full stripping of front (1–500mm) and rear (1–300mm) ends for complex cable specifications.
High Precision & Efficiency: With a stripping accuracy of ±0.2mm and a production rate of 1500–2000 pieces/hour (for 200mm length cables), it ensures consistent quality while maximizing throughput. The imported high-speed steel blades and servo-driven ball screw system guarantee stable, long-lasting performance.
Technical Parameters:
| Parameter | Specification |
|---|---|
| Dimensions (L×W×H) | 1260 × 830 × 1170 mm |
| Weight | 275 kg |
| Power Rating | 5500 W |
| Display Mode | Switchable bilingual (Chinese/English) interface |
| Max Outer Diameter of Round Sheath | ≤ 25 mm |
| Max Conductor Cross-Section | 2.5–185 mm² (max 120 mm² for BV hard wire; max 185 mm² for BVR flexible wire) |
| Stripping Accuracy | ±0.2 mm |
| Max Conduit Diameter | 27 mm (motor-driven jump conduit, no air supply required) |
| Max Cutting Length | 400 m |
| Full Sheath Stripping Length | Front end: 1–500 mm; Rear end: 1–300 mm (for 150 mm² cables) |
| Stripping Length Range | Front end stripping: 1–100 mm; Rear end stripping: 1–100 mm |
| Blade Material | Imported high-speed steel |
| Servo High-Speed Cutting & Stripping | 1500–2000 pieces/hour (based on 200 mm length) |
| In/Out Feed Roller Drive | Screw motor lifting rollers, upper/lower pressure rollers auto-adjustable |
| Drive System | 8-wheel belt drive (silent hybrid stepper motor, 0.1 mm step resolution) |
| Tool Post Drive System | Servo motor driver + precision ground ball screw |
