Feature：
High Precision: Test accuracy of ±0.04N ensures reliable and consistent measurement results.
Adjustable Test Speed: Speed range of 10–800mm/min (JC-Q50/Q100) or 10–400mm/min (JC-Q300) for flexible testing conditions.
Multiple Force Ranges: Choose from 500N, 1000N, or 3000N models to suit light-duty to heavy-duty applications.
Compact & Durable Design: Sturdy construction with compact dimensions, ideal for production lines and laboratory environments.
Easy Operation: User-friendly interface and straightforward setup for quick testing and data recording.
Technical Parameters：
| Brand | Jingcheng | Jingcheng | Jingcheng |
|---|---|---|---|
| Product Name | Electric Pull Force Tester | Electric Pull Force Tester | Electric Pull Force Tester |
| Model | HY2-A50 | HY2-A100 | HY2-A300 |
| Test Range | ≤500N | ≤1000N | ≤3000N |
| Test Accuracy | ±0.04N | ±0.04N | ±0.04N |
| Test Speed Range | 10–800mm/min | 10–800mm/min | 10–400mm/min |
| Power Rating | 100W | 100W | 300W |
| Power Supply | AC 220V, 50/60Hz | AC 220V, 50/60Hz | AC 220V, 50/60Hz |
| Dimensions (L×W×H) | 430 × 180 × 210mm | 430 × 180 × 210mm | 480 × 260 × 240mm |
| Net Weight | 10kg | 12kg | 21kg |
