Feature：
Pneumatic-driven, no power required: Operates only with an air supply, no electricity needed.
High precision & safety: Accurate stripping positioning, one-touch operation without foot pedal, safe and reliable.
Easy adjustment: Stripping length, cutting depth, half/full stripping are all adjustable via calibrated knobs, no tools required.
Universal 90° V-blade design: Compatible with different wire types without changing blades.
Wide processing range: AWG32 to AWG14 (0.03–2mm wire diameter).
Adjustable stripping length: 1mm–20mm.
Compact & portable: Lightweight (only 2kg), easy to move, works anywhere with an air supply.
Technical Parameters：
| Parameter | Specification |
|---|---|
| Model | QS-2015C |
| Processing Range | AWG32–AWG14 |
| Functions | Outer insulation stripping, half-stripping with residual insulation, full stripping. |
| Working Principle | Air-driven only, no electricity required, fast and eco-friendly. |
| Production Capacity | 1800–2000 pcs/hour (depends on operator proficiency) |
| Stripping Length Range | 1–20mm |
| Adjustment Accuracy | 0.05mm |
| Working Air Pressure | 0.5–0.7MPa (Note: The unit "Pa" in the original table is likely a typo; standard air pressure for such tools is in MPa) |
| Dimensions (L×W×H) | 265 × 70 × 135mm |
| Machine Weight | 2kg |
| Country of Origin | China |
