Model

HY10-A848PL

Mechanical dimensions

L1600 × W480 × H1200 (mm)

Box size

L800 × W480 × H280 (mm)

Heating space

L800 × W400 × H150 (mm)

Mechanical weight

65kg

Conveying speed

0~6m/min

Mechanical power

6KW (3.6KW optional)

Conveying capacity

20kg

Material of conveyor belt

High-temperature-resistant Teflon mesh belt

Heating temperature

0~260℃

Heating method

Dual temperature control (double-sided heating)

Heating tube

Far-infrared heating tube

Hot air fan

Yes

Heat dissipation device

Yes

Belt guide

Yes

Power supply

AC 380V (AC 220V optional), 50Hz
