Model No.

HY2-A612X

Display Mode

7-inch HMI (Human-Machine Interface)

Functions

1. Processing of large cables such as power cords, corrugated wires, base station coaxial cables, electric cables, multi-core wires, multi-layer wires, shielded wires, and new energy vehicle charging pile cables.2. Adopts rotary cutting mode; no need to replace blades, able to cut and strip cables of all specifications. Supports storage of 100 sets of processing parameters and recipes.

Wire Type

Single-core wire, multi-core wire, power cord, multi-layer wire, shielded wire, electric wire, etc.

Processing Range

6 – 120 mm²

Cutting Length

1mm - 999999.99mm

Cutting Tolerance

Within 0.002×L (L = Cutting Length)

Stripping Length

Front full strip: 1-300mm, Front half strip: 1-1000mmRear full strip: 1-150mm, Rear half strip: 1-500mm

Max Conduit Diameter

Φ24mm

Lifting Wheel Mode

Stepper motor driven lifting wheel

Conduit Swing Mode

Cylinder driven conduit swing

Cutter Material

High-quality imported high-speed steel

Production Capacity (pcs/hour)

800-1000 PCS/hour (Depends on wire length and cross-section)

Driving Mode

24-wheel drive (Feeding stepper motor, tool rest servo motor); Servo feeding optional for R version

Wire Feeding Mode

Belt feeding, no indentation or scratch on cables. (With stripping pressure function)

Lifting Operation Mode

Digital adjustment of pressure wheel height

Rotary Stripping Cutter Feeding Mode

Precision ground lead screw

Rotary Stripping Blade Material

High-speed steel / Tungsten steel (Optional)

Number of Rotary Stripping Blades

2 pcs

Rotary Stripping Blade Power

Feeding: Servo drive; Rotation: Servo drive

Rotary Stripping Auxiliary Clamp

Servo + precision ground lead screw

Power Supply

AC 220V 50/60Hz; 110V 50/60Hz optional for R version

Air Supply

Clean air source of 0.5-0.8Mpa

Packing Dimension (L×W×H)

1400×720×1460 mm

Net Weight

300KG
