Cutting Material Type

Wires, cables, flat ribbon cables, flexible copper busbars, protective sleeves and various PVC hoses

Processing Range

1 – 150 mm²

 Cutting Length

1mm – 9999999.99mm

Cutting Tolerance

Within 0.002L for wires (L=cutting length)Within 0.003L for hoses (L=cutting length)

 Stripping Length

Front stripping: 1 - 800mm (wire head)Rear stripping: None (wire tail)

 Max Wire Diameter

Φ33mm

Cutter Material

Imported high-speed steel

 Productivity

1800 PCS/h (Depends on wire length and size)

 Power Configuration

Cutting knife servo motor, feeding stepping motor; full servo optional

 Wire Feeding Mode

Belt feeding, no indentation or scratch on cables, 16-wheel drive

 Winding Power

Servo motor

 Winding Turns

Digital setting: 1 – 99 turns

Winding Position

Digitally adjustable, arbitrary position

 Tape Positioning

Digitally adjustable

Power Supply

220V/50HZ ±10%

Installed Power

1.6KW

 Full Load Current

18A (Minimum allowable current: 10A)

Air Source

Not required

Special Function

Customizable for special cables; sample wire testing required

 Special Function

Stripping pressure function, front full-stripping guide pipe, automatic wire feeding detection

 Optional Accessories

Material collecting clamp, material collecting manipulator, wire take-up stand. (Module isolation is required during use)
