Processing Range: 0.75 – 50 mm²

Cutting Length: 1mm – 999999.99mm

Cutting Tolerance: Within 0.002×L (L = cutting length)

Stripping Length:

Front full stripping: 1–200mm; Front half stripping: 1–1500mm

Rear full stripping: 1–100mm; Rear half stripping: 1–300mm

Max Passable Diameter: Φ20

Blade Material: Premium imported high-speed steel

Productivity: 3500 PCS/hour (depends on wire length and wire size)

Driving Mode: 16-wheel drive; feed stepping motor + cutter holder servo motor; servo feed is optional

Wire Feeding Mode: Belt feeding design, no indentation or scratch on cables (with stripping pressure function)

Height Adjustment: Digital adjustment of pressure roller height

Power Supply: AC220V 50/60Hz; 110V 50/60Hz optional

Air Supply: Clean air source at 0.5Mpa

Dimension (L×W×H): 680×605×520 mm

Net Weight: 90kg

Optional accessories:

MES system, IoT system, fixed-point inkjet marking function, middle stripping function, external auxiliary equipment alarm.

User-friendly system, intuitive operation via 7-inch color touch screen.

Modular interface, easy to connect with accessories and peripheral equipment.

Modular design, support future upgrading.

A variety of optional parts are available with customizable system configuration.

Non-standard customization is acceptable for special wire and cable processing requirements.
