parameter
Item | Specification |
Model | HY2-A603YJ (With worktable and manipulator) |
Display Mode | 7-inch HMI |
Function | Fully automatic fixed-length cutting and stripping for single-core wire, multi-core cable and shielded cable |
Applicable Wire Type | Single-core wire, multi-core cable, shielded cable, electric wire, PVC wire, etc. |
Processing Range | 0.75 – 30 mm² |
Cutting Length | 1mm – 999999.99mm |
Cutting Tolerance | Within 0.002×L (L = cutting length) |
Stripping Length | Front full stripping: 1–200mmFront half stripping: 1–1500mmRear full stripping: 1–100mmRear half stripping: 1–300mm |
Max Allowable Passing Diameter | Φ18 |
Cutter Material | High-quality imported high-speed steel |
Productivity | 3500 PCS/hour (depends on wire length and size) |
Driving Mode | 16-wheel drive (feeding stepper motor, cutter rest servo motor); servo feeding optional |
Wire Feeding Mode | Belt feeding, no indentation or scratch on cables (with stripping pressurization function) |
Lifting Operation Mode | Digital adjustment of pressure roller height |
Power Supply | AC220V 50/60Hz; 110V 50/60Hz optional |
Air Source | Clean air source: 0.5Mpa |
Dimension (L×W×H) | 707×590×1140 mm |
Net Weight | 140 kg |
Remarks | Ultimate cutting capacity up to 50 mm² |
Feature:
Optional configurations: MES system, IoT system, fixed-point inkjet marking function, middle stripping function, external auxiliary equipment alarm.
User-friendly system with intuitive operation via 7-inch color touch screen.
Modular interface for easy connection with accessories and peripheral devices.
Modular design, support for future upgrades. A variety of optional accessories are available with customizable system configuration. Non-standard customization is available for special wire and cable processing.
