Processing Range: 0.75 -- 30 square millimeters

Cutting Length: 1mm - 999999.99mm

Cutting Tolerance: Within 0.002L (L = cutting length)

Stripping Length:

Front full stripping: 1-200mm; Front half stripping: 1-1500mm

Rear full stripping: 1-100mm; Rear half stripping: 1-300mm

Max Allowable Passing Diameter: Φ18

Cutter Material: High-quality imported high-speed steel

Productivity (pcs/hour): 3500 PCS/hour (subject to wire length and wire gauge)

Driving Mode: 16-wheel driving; feeding stepper motor, tool rest servo motor; servo feeding optional

Wire Feeding Mode: Belt wire feeding, no indentation or scratch on cables (with stripping pressurization function)

Lifting Operation Mode: Digital pressure roller height adjustment

Power Supply: AC220V 50/60Hz; 110V 50/60Hz optional

Air Source: 0.5Mpa clean air source

Dimension (LWH) mm: 680605*520

Net Weight: 90kg

Optional Configuration:

MES system, IoT system, fixed-point coding function, middle stripping function, external auxiliary equipment alarm.

User-friendly system with intuitive operation via 7-inch color touch screen.

Modular interface for easy connection of accessories and peripheral equipment.

Modular design allows future upgradeability.

Various optional accessories are available with customizable systems. Non-standard customization is supported for special wire and cable processing.
