Feature:
Main Frame Material: Made of high-quality carbon steel with sheet metal bending and welding process, featuring solid structure and elegant appearance.
Parameter | AFL65 | AFL85 |
Model | AFL65 | AFL85 |
Drive Mode | Three-phase motor + reducer | Three-phase motor + reducer |
Rated Speed | 1450 rpm | 1450 rpm |
Max Speed | 2200 rpm | 2200 rpm |
Wire Reel Outer Diameter | 100–650 mm | 100–850 mm |
Through Hole Diameter | 38–200 mm | 38–200 mm |
Wire Reel Height | 650 mm | 850 mm |
Installation Type | Mounted through reel inner bore | Mounted through reel inner bore |
Material Type | With or without packaging | With or without packaging |
Placement | Vertical | Vertical |
Speed Control | Adaptive stepless speed regulation | Adaptive stepless speed regulation |
Max Load Capacity | 100 kg | 200 kg |
Motor Power | 0.75 kW | 1.5 kW |
Max Wire Diameter | 30 mm | 30 mm |
Protection Form | Double-side edge protection | Double-side edge protection |
Overall Dimensions | 1544 × 660 × 1244 mm | 1544 × 850 × 1344 mm |
Packing Dimensions | 1600 × 760 × 800 mm | 1644 × 950 × 800 mm |
