Desktop Semi-automatic Piercing Machine HY2-ALD01
Automotive Wiring Harness >

Features Description:

※ Magazine-type fast feeding design enables material replacement in just 1 minute. It adopts computerized automatic detection, which can monitor low air pressure, motor abnormality, belt abnormality and other faults. The machine will stop automatically when abnormalities occur and display fault causes for quick and convenient troubleshooting;

※ It features simple adjustment and short adjustment time, greatly reducing machine setup time;

※ The crimping position can be adjusted via touch screen for more precise and stable terminal crimping; ※ Supports rapid product switching within a short time.




Specifications:

Specifications

Parameters

Model

HY2-ALD01



Power Supply

AC 220V / 50/60 Hz, Single Phase

Air Pressure

5 - 6 kgf (Clean dry air required)

Functions

Insulation Piercing Crimping (IPC)

Processing Range

2P - 30P

Production Capacity

3600 PCS/hour (Depending on product specifications)

Crimping Accuracy

±0.01mm

Machine Dimensions

L750 × W530 × H520mm (Excluding protrusions)
