Parameter | Specification |
Wire Gauge Range | 0.2–4 mm² (larger sizes customizable) |
Cutting Length | 50 mm–9999 mm (settable in 0.1 mm increments; shorter lengths customizable) |
Stripping Length | 1 mm–15 mm (stripping length customizable) |
Crimping Force | Servo terminal machine |
Crimping Stroke | 30 mm (40 mm stroke customizable) |
Applicable Dies | Universal OTP pneumatic pre-insulated terminal dies |
Detection Systems | Air pressure detection / Wire presence detection / Terminal presence detection / Crimped terminal presence detection(Pressure management optional) (Vision system optional) |
Control Mode | Motion control card |
Functions | Wire cutting, single/double-end stripping, single/double-end crimping |
Production Efficiency | 2600–3200 cycles/hour (customized models subject to actual output) |
Compressed Air Requirement | ≥0.55 MPa |
Power Supply | Single-phase AC220V, 50/60Hz, 32A |
Overall Dimensions | L1100 × W900 × H1800 (mm) (excluding protrusions) |
Major Component Brands | Taiwan TBI ball screws, Taiwan AirTAC cylinders, AirTAC linear guides, Japan NSK bearings, well-known brand servo motors |
Full Servo Double Head Wire Crimping Machine
feature：
This Full Servo Double-End Crimping Machine features full-servo driven control for high-precision, stable, and low-noise crimping operations. It supports automatic wire feeding, cutting, stripping, and simultaneous double-end terminal crimping, ensuring consistent crimp quality and production efficiency.
