Technical Parameters：
model | HY2-A16 |
|---|---|
| Power supply | AC 220V 50/60Hz(one phase) |
| Pressure force | 5-6 kgf (requires clean air) |
| Function | Wire cutting,one side stripping,two sides stripping,one side crimping,one side plug-in plastic housing,one side partial stripping,one side twisting,one side tin coating |
| Wire color | Corresponding to 12 colors(same specifications) |
| Quality detection | Pressure management system,CCD terminal appearance inspection system,creepage force detection,terminal pull force detection,presence of wires,wire connectors,presence of terminals,presence of sockets |
| Range of processable wires | AWG#30—AWG#18 |
| Production Capacity | 1800 PCS/HOUR(depending on the product) |
| Cutting length | 45mm-3000mm |
| Cutting accuracy | 1mm +cutting length×less than 0.1% |
| Stripping length | 0-7mm |
| Crimping capacity | 2.0T |
| Size | 19009201600mm(excluding protrusions) |
